Channels

1-32 channels, 1-64 channels, 1-96 channels

(three specifications of chassis)

Interface type

USB3.0 interface

Software operating environment

Win7, 64 bit operating system

A/D conversion accuracy

16bit

Sampling rate

10MHz (synchronous acquisition of all channels)

Continuous data pass rate

大于300MB/S

Input signal range

±10V

Host system noise

± 1 sampling resolution, i.e. ± 0.308mV

Parameter type

All acoustic emission parameters specified

in national standards

Parameter pass rate

Greater than 200000 sets/second

Channel input impedance

50Ω

Nonlinear error of A/D conversion

±0.5LSB

Signal input type

single-ended

Sampling trigger method

Signal threshold triggering

Number of external reference channels

6channels

External parameter conversion accuracy

16bit

External parameter input range

±5V or ±10V

Operating temperature range

0℃～50℃

Power supply mode

External 220V power supply
